| Brand | PNY |
| Model | VCQGP100-PB |
| Interface | PCI Express 3.0 x16 |
| Chipmaker | NVIDIA |
| GPU | Quadro GP100 |
| CUDA Cores | 3584 |
| Memory Size | 16GB |
| Memory Interface | 4096-bit |
| Memory Type | HBM2 |
| DirectX | DirectX 12 |
| OpenGL | OpenGL 4.5 |
| DisplayPort | 4 x DP 1.4 |
| DVI | 1 x DL-DVI-D |
| Digital Resolution | Maximum DP 1.4 Resolution: HDR 7680 x 4320 at 30 Hz (30-bit color) |
| Max Displays Per Board | 4 |
| SLI Supported | NVLink (2-way) or SLI HB |
| Cooler | Ultra-quiet active fansink |
| Dual-Link DVI Supported | Yes |
| HDCP Ready | Yes |
| Operating Systems Supported | Microsoft Windows 10 (64-bit and 32-bit)Microsoft Windows 8.1 and 8 (64-bit and 32-bit)Microsoft Windows 7 (64-bit and 32-bit)Linux - Full OpenGL implementation, complete with NVIDIA and ARB extensions (64-bit and 32-bit) |
| System Requirements | Maximum Power Consumption: 235WMinimum System Hardware Requirements:Intel Core i5, i7, Xeon or laterAMD Phenom or Opteron-class or laterPCIe x16 Gen 3 (preferred) expansion slot2GB or more of system memory, 8GB recommended200MB of available disk space for full driver installationBlu-ray or DVD-ROM driveInternet connection (if preferred for driver installation)DisplayPort (preferred) or DVI compatible displaysHDMI display(s) with purchase of optional DP to HDMI adapter(s) |
| Features | Full-Scene Antialiasing (FSAA)16K Texture and Render ProcessingPascal Memory CompressionNVIDIA Quadro MOSAIC TechnologyNVIDIA NVIEW Advanced Desktop SoftwareNVIDIA Quadro Sync IIFrame Lock Connector Latch OpenGL Quad Buffered Stereo SupportUltra High Resolution Desktop Support Professional 3D Stereo Synchronization NVIDIA CUDA Parallel Computing PlatformUnified MemoryNVIDIA GPUDirect for VideoNVIDIA Enterprise-Management ToolsNVIDIA NVLink High Speed InterfaceNVIDIA SLI HB Technology |
| Dimensions (L x H) | 10.50" x 4.40" |
| Package Contents | NVIDIA Quadro GP100 professional graphics boardDisplayPort to DVI-D SL adaptersAuxiliary power cableSoftware installation disc for Windows 10, 8.1, 8, and 7 (64- and 32-bit)Printed Quick Start Guide |
| Slot Width | Dual Slot |
| Country Of Origin | China |
